Infrastructure

Manufacturing facilities, all in-house

From sheet steel to a tested, powder-coated panel: every stage happens at our plant in Greater Noida.

Two open floor-standing panels during assembly

Our Machinery

CNC machines for every stage of fabrication

Cutting, forming, busbar processing, pre-treatment and powder coating all run on our own machines at the Greater Noida plant.

View all machinery

Cutting
CNC Laser Cutting Machine
Fine, burr-free profiles for complex panel parts.
Cutting
CNC Punching Machine
Accurate, repeatable punching of panel sheets and cut-outs.
Cutting
CNC Shearing Machine
Clean, square cuts on CRCA sheet steel for every enclosure.
Forming
CNC Bending Machine
Precise forming of doors, frames and covers.
Busbars
Busbar Bending, Cutting & Punching Machine
Busbars processed in-house to the exact design.
Cable trays
Cable Tray Perforation Line
In-house perforation of cable trays in a range of sizes.
Finishing
7-Tank Chemical Pre-Treatment Plant
Surface treatment before powder coating for long-lasting adhesion.
Finishing
Powder Coating Oven
Spray booth and curing oven for a durable, even finish.

Inspection & Testing

Every panel is tested at the plant

We have complete in-house panel testing facilities.

Inspection and testing at the plant
Insulation testing up to 1000 megohms
High-voltage test: 2.5 kV for 1 second (50 Hz)
Functional testing and powder coating quality inspection
Aluminium (Al) and copper (Cu) conductivity testing (% IACS)
kWh meter calibration
Primary injection testing up to 4000 A
Secondary injection testing
Switchgear operational testing

Trident panel testing bench with meters and switches

Engineer testing an air circuit breaker inside an LT panel — ACB TestingAir circuit breakers checked inside the finished panel.

High-voltage test being carried out on a panel — High-Voltage TestingDielectric strength verified before dispatch.

Engineers carrying out insulation resistance testing on a panel — Insulation Resistance TestingInsulation measured on every panel.

Inspector checking powder coating thickness on a panel door — Powder Coating Thickness InspectionCoating thickness checked on enclosure surfaces.

Test Equipment

Calibrated instruments for every test

Our test bay is equipped with:

High voltage meter
Megger (1000 V)
Multimeter
Tong tester
Clamp meter
kWh meter (load calculation meter)
Digital harmonics measuring meter
Current transformer
Voltage transformer
Analyser
Digital frequency meter
Digital ammeter
Digital voltmeter
Digital power factor meter & controller

Gallery

From our shop floor

Quality · Safety · Compliance · Trust

Certified, type-tested and independently verified

Our quality system and panel designs are backed by independent certification and testing.

ISO 9001:2015

DGACERT Management System Pvt. Ltd. (UKACF accredited)

Quality management system certified for the manufacturing of electrical panels. Certificate no. 22800553637QM, valid until 22 September 2029.

View document

CE Certificate of Compliance

British Columbia Inspection & Certification (BCI)

Certificate of compliance confirming conformity with the requirements of the CE marking directives and regulations applicable within the European Union.

View document

CPRI provisional short-circuit test report for a Trident PCC panel

CPRI Short-Circuit Test

Central Power Research Institute, Bhopal

PCC panel rated 415 V, 4000 A tested to IS 8623 (Part 1): withstood 50 kA for 1 second with a 105 kA peak and no abnormality, then passed a 2.5 kV high-voltage test for one minute (provisional report S2121204).

View document
